Brute strength meets intelligent design.
Designed for the biggest camera packages in the world.
NOW SHIPPING
Crafted for legendary performance.
MotoCrane HYPER is a no-compromise remote arm system that combines new, lightweight aluminum chassis structures with high-power brushless motor drives for throwing around massive payloads and brutal speeds.
Not for the weak-hearted.
LARGE CONSTRUCTION
An internally reinforced turret structure comprised of nearly 100% aluminum results in low weight and high structural rigidity. The arm design takes advantage of tall z-axis bracing for increased stiffness. Opposing braided steel turnbuckles provide lateral stiffness for reducing flex during heavy acceleration, cornering, and braking.
BIG POWER
With a combined peak power of 6000W, both Lift and Swing axes are outfitted with large brushless motors for responsive control, and blazing fast arm speeds. The Swing axis generates 4000 ft-lbs of torque, and completes a 360° revolution in less than 5.5 seconds.
STRUCTURALLY INTEGRATED
While it’s smaller brothers represent the most portable and universal remote arm technology in the world, HYPER is designed for our customers with semi-permanent integration to a dedicated tracking vehicle. We are happy to work with your fabricator on vehicle integration.
Built for the biggest.
120lbs payload capacity for direct compatibility with the largest stabilized heads in the industry.
Put the camera where you want.
(even at speeds over 100mph)
Seamless connections for gear.
MotoCrane HYPER is just 1 piece of the tracking vehicle puzzle. With streamlined peripheral integrations, it’s easy to connect power, video, and comms for your gimbal, video accessories, and any other equipment.
Enjoy 360° unlimited swing rotation, while passing up to 50 amps of accessory power (5-60VDC), and up to 6 channels of accessory comms from inside the vehicle. The 3G-SDI slipring also makes it simple to pass video signal through HYPER for wiring monitors within the vehicle.
The HYPER Powerlink is a low-profile connection hub for accessory power, accessory coms, and the arm controller. Connect AC power via the vehicles cigarette lighter, and the Powerlink will also charge HYPER’s inactive battery bank for continuous non-stop arm operation.
Intelligent, redundant power storage.
Power dense and feature-packed - the HYPER counterweight makes use of unused mass, resulting in lower all-up weight and simpler operation of the system. Most notably, the HYPER counterweight houses dual 48v 22ah power banks. While 1 bank actively powers the arm, the other bank is charged via the Powerlink from within the vehicle.
In addition to the dual 48v battery banks, the counterweight also features the CORTEX Motor Controller Unit - a single, weather resistant, serviceable motor controller unit responsible for all power delivery, motor controls, diagnostics and data processing.
MotoCrane HYPER includes INS 2 Advanced Stabilization as standard equipment.
With high structural rigidity and a zero-backlash Lift axis- HYPER delivers rock solid arm stabilization for maintaining lens elevation on uneven terrain. The INS 2 Sensor Module mounted to the front boom features a fully calibrated and temperature compensated triaxial accelerometer and gyroscope to achieve the optimum combination of measurement qualities under all dynamic conditions.
Get working with your MotoCrane now - pay on a schedule that works for you.
HYPER includes our latest generation of arm controller - the COMMAND Console PRO which features an all-new, full-color touchscreen user interface for controlling, configuring and monitoring every aspect of HYPER. Designed 100% in-house at MotoCrane, and machined from a single billet of 6061 aluminum, it is optimized for intuitive and effective arm operation.
Looking to integrate HYPER into your vehicles?
Download the 3D CAD for the HYPER Base mounting plate below.
HYPER is ready for action.
As you prepare your vehicle for MotoCrane HYPER, our engineers are ready to work with you/your fabricator to ensure proper fitment and structural integrity of your build. We maintain close relationships with our customers, and look forward to hearing from you about your application
Are you ready for HYPER?
NOW SHIPPING
